Written in C. I wanted to try my hand at creating an image format with lossy compression, without
doing much research on how other image formats worked. I did notice that jpegs seem to be split into
tiles, which gave me the idea to use a tile based approach in my own format. I'm not great at C so
the code isn't amazingly well organised. The files starting with stb_* and the harness.c were not
written by me.
First, it checks if the image contains any transparency, and if it doesn't we set a flag at the start
of the file and use RGB instead of RGBA for the rest of the file, saving space.
Then it splits the image into 8x8 tiles, and checks if each follows one of these criteria. It does
this by computing the sum of the difference squared between the actual image data, and how it will
look when decoded.
- Find the average color of the tile, if the tile as a whole is close to being a solid square of
that color, just save it as a solid tile with that average colour (storing in 4/5 bytes, flag +
rgb(a)).
- If not, try the same with a 4 point gradient on each of the corners (storing i).
- If not, does it only have 2 colours, we can store it using 1 bit per pixel.
- If not, does it only have 16 colours, we can store it using 4 bits per pixel.
- If not we store the full image data.
In the case of a tile that will be encoded using a solid block or gradient, I compute the DFT, using
the Cooley-Tukey radix-2 FFT algorithm (as the tiles are guarenteed to be 8x8 anyway), to isolate
the high frequency noise in that tile, and encode just the magnitude of this noise, so it can be
approximated in decoding. The noise pattern will not be the same, but someone looking at the image
hopefully wouldn't be able to tell that.
The resulting bytes are then compressed using huffman encoding.
Also I lowk forgot to ever get around to making it work with images that have dimensions not
divisible by 8, so it just crops.
